Description
ALIF1002R-US Includes Only:
- ALIF1002R unit
- Power adapter (20W) and country-specific power cord
- Quick setup guide
Features:
- ‘At-the-PC’ experience: single link or single head, 24 bits per color at a maximum resolution of 1920 x 1200 at 60Hz with minimal lag
- Adaptable to suit your needs: delivers uncompressed digital video with audio, and the option to compress video to minimize bandwidth usage over copper or fiber
- IP-based: standard IP protocols, ensuring maximum compatibility with your existing IT infrastructure and staff skillset
- Flexible solution: from point-to-point extender to an infinitely extensible matrix
- In-built security measures: compliant with universal enterprise-grade security standards (AES 256 bit encryption and RSA 2048 bit public key authentication)
As part of the AdderLink™ Infinity range, AdderLink Infinity 1002 is a high-performance KVM extender that enables you to locate your critical computing hardware in a secure and temperature-controlled environment, isolated from the user work station. Configurable as a single head or single link, this extender provides pixel-perfect video with minimal lag across a distance of up to 10km. This KVM extender can be used as a point-to-point extender or integrated into a wider matrix system when combined with the AdderLink Infinity Manager (AIM).
Perfect digital video
Uncompressed video extension and pixel-perfect digital video up to 24 bits per color at a maximum of 1920×1200 single link or single head with real-time control.
Digital Stereo Audio
Digitally delivered crystal clear audio across the network.
Distribution
Distribution of DVI-D, USB, audio and bidirectional RS232 across up to 10km.
Power redundancy
The units can detect whether the network is in operation and will utilize the second network port if failure is detected.
EDID management
Extended Display Identification Data (EDID) enables the remote system to exactly mirror the data coming from the source monitor.
Plug and Play
The AdderLink Infinity range is delivered in a zero-config state so they work as soon as they are connected, without the need for drivers or software.
Robust yet lightweight
Small form factor, rack-mountable device.
USB True Emulation
USB2.0 enables connection to any USB human interface device from mice and keyboards through to graphics tablets, jog shuttles, joysticks and 3D explorers.
ALIF 1002 receiver – front:
ALIF 1002 receiver – rear:
| Casing (w x h x d) | 198mm (7.92″) x 44mm (1.76″) x 150mm (6.0″) |
| Construction | 1U compact case, robust metal design |
| Weight | 1.1kg (2.4lbs) |
| Mount kits | Rackmount – single or dual units per 1U slot. VESA monitor/wall-mount chassis. |
| Power to adapter | 100-240VAC 50/60Hz, 0.8A, |
| Power to unit | 5VDC 20W |
| Operating temp | 0°C to 40°C (32°F to 104°F) |
| Approvals | CE, FCC |
