Adder ALIF2020R-US AdderLink Infinity Dual KVM Receiver

Description

ALIF2020R-US Includes Only:

• ALIF2020R-US unit
• Power adapter (20W) and country-specific power cord
• Quick setup guide

Features:

• ‘At-the-PC’ experience: single link and dual head, 24 bits per color on a maximum resolution of 1920×1200 at 60Hz with minimal lag
• Adaptable to suit your needs: delivers uncompressed digital video with audio, and the option to compress video to minimize bandwidth usage over copper or fiber
• IP-based: standard IP protocols, ensuring maximum compatibility with your existing IT infrastructure and staff skillset
• Flexible solution: from point-to-point extender to an infinitely extensible matrix
• In-built security measures: compliant with universal enterprise-grade security standards (AES 256 bit encryption and RSA 2048 bit public key authentication)
• Perfect digital video: uncompressed video extension and pixel perfect digital video up to 24 bits per color at a maximum of 1920×1200 over 60Hz with real-time control
• Digital Stereo Audio: digitally delivered crystal clear audio across the network
• Distribution: DVI, USB, audio and bidirectional RS232 across up to 10km
• Power redundancy: the units can detect whether the network is in operation and will utilize the second network port is failure detected
• EDID management: Extended Display Identification Data (EDID) enables the remote system to exactly mirror the data coming from the source monitor
• Plug and Play: the AdderLink Infinity range is delivered in a zero-config state so they work as soon as they are connected, without the need for drivers or software
• Robust yet lightweight: small form factor, rack-mountable device
• USB True Emulation: USB 2.0 enables connection to any USB human interface device from mice and keyboards through to graphics tablets, jog shuttles, joysticks and 3D explorers

Part of the AdderLink™ Infinity range, the AdderLink™ Infinity Dual 2020 is a high-performance KVM solution that enables you to isolate critical computing hardware in a secure and temperature-controlled environment. Configurable as a single link or dual head, this extender provides an ‘at-the-PC’ experience across up to 10km: the digital video you receive is the same as the digital video leaving the remote computer, with no loss of compression and minimal lag. The Dual 2020 comes with a choice of single-mode or multimode fiber modules to suit your specific application. This KVM extender can be used as a point-to-point extender or can be integrated into a wider matrix system when combined with the AdderLink Infinity Manager (AIM).
